Worm gear hand winch 200 - 7500 kg Ref: 156-1

This large worm gear winch has, as the name implies, a worm gear transmission. This type of transmission, in combination with the load-pressure brake, ensures that this winch is a very safe winch. In addition, the large worm gear winch is easy to use and can be mounted in any position. The winch also has space for a large cable storage.

• Robust and safe lifting and pulling winch in compliance with EN13157, DIN 15020
• Static safety factor 4
• Two lifting speeds
• Right angled, easy to grease worm transmission and maintenance free bearings
• Load pressure brake with double ratchet system for safe stable hold of the load
• Cable outlet upwards, downwards or at rear
• Adjustable crank, with ergonomic grip
• Suitable for wall and floor mounting
• Large rope capacity
• Simple and quick attachment
• Paint thickness 60 – 80 micron in 1 layer and in compliance with C1M – RAL7035 (grey)
• Corrosion resistant

Options

1. GD = Grooved cable drum
2. EV = Zinc plated finish with a minimum of 6 micron
3. EX = ATEX certified, for zones 2 and 22
4. XD = Multiple (X) cable compartments possible
5. 2D = Twin Drum LINK
