YOKE Grade 100 Clevis Self Locking Hook

YOKE SKU: 276-58-1

1 2

YOKE Grade 100 Clevis Self Locking Hook

YOKE Grade 100 Clevis Self Locking Hook Quenched and Tempered Alloy Steel At least 25% greater WLL than traditional G80 products Manufactured... Read More

YOKE SKU: 276-58-1

€45,17

RRP TODAY'S PRICE €45,17

In stock

Tax included.

Product variants

This product is NOT available Online.

Please contact us via email for availability and delivery to Europe sales@rigging-eu.com

View full details

Need More?

Require more stock than shown as available, please send us your requirements via email sales@rigging-eu.co.uk

Need Help?

If you're unable to locate the specific item you're searching for, please send us your requirements via email sales@rigging-eu.co.uk

Description

YOKE Grade 100 Clevis Self Locking Hook

Quenched and Tempered Alloy Steel
At least 25% greater WLL than traditional G80 products
Manufactured in accordance with EN 1677- 3 and ASME B30.26, ASME B30.10, PAS1061
Certified by DGUV GS-OA-15-05
Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
Design Factor 4:1
Fatigue rated to 20,000 cycles at 1.5 times the WLL
Tempering temperature minimum 400°C
Magnaflux crack detection is performed 100% on each batch

Spec

SKU	Capacity (t)	For Grade 100 Chain (mm)	Weight (kg)
276-58-1	1.4	6	0.4
276-58-2	2.5	7, 8	0.9
276-58-3	4	10	1.4
276-58-4	6.7	13	3
276-58-5	10	16	5
276-58-6	16	20	11
276-58-7	19	22	13.5
