| SKU | Reservoir Capacity | Volume Per Stroke cc | Volume Per Stroke cc | Piston Dia. mm | Piston Dia. mm | Piston Stroke | Max Hand Effort | Weight | Working Pressure |
|---|---|---|---|---|---|---|---|---|---|
| cc | High Pressure | Low Pressure | High Pressure | Low Pressure | mm | kgs | kgs | kgf/cm2 | |
| 286-708-5 | 800 | 2 | 13 | 11 | 28 | 20.5 | 29 | 4 | 700 |
| SKU | Reservoir Capacity | Volume Per Stroke cc | Volume Per Stroke cc | Piston Dia mm | Piston Dia mm | Piston Stroke | Max Hand Effort | Weight | Working Pressure |
|---|---|---|---|---|---|---|---|---|---|
| cc | High Pressure | Low Pressure | High Pressure | Low Pressure | mm | kgs | kgs | kgf/cm2 | |
| 286-708-6 | 1,600 | 2.0 | 16.5 | 11 | 32 | 20.5 | 44 | 8 | 700 |
| SKU | Reservoir Capacity | Volume Per Stroke (cc) | Volume Per Stroke (cc) | Piston Dia. (mm) | Piston Dia. (mm) | Piston Stroke | Weight | Quality of material | Working Pressure |
|---|---|---|---|---|---|---|---|---|---|
| (cc) | High Pressure | Low Pressure | High Pressure | Low Pressure | (mm) | (kg) | (kgf/cm2) | ||
| 286-708-7 | 2300 | 2.3 | 31 | 12 | 44 | 20.5 | 10.5 | Aluminium | 700 |
